Genset model
|
CN400GF
|
|
|
Genset rated power
|
400KW/500KVA
|
|
|
Rated voltage
|
400/230V (adjustable)
|
|
|
Rated current
|
720 Amps
|
|
|
Frequency
|
50 Hz
|
|
|
Power factor
|
0.8 Lagging
|
|
|
Connecting type
|
3 phase 4 wire
|
|
|
Cooling system
|
Closed cycle water-cooled with fan, water tank
|
|
|
Overall dimension (L×W×H) mm
|
3100×1100×1650
|
|
|
Gross weight (kg)
|
3200
|
|
|
Diesel Engine
|
||
|
Brand
|
YUCHAI
|
|
|
Model
|
YC6T660-D31
|
|
|
Engine type
|
6 cylinders vertical in Line, 4 stroke,
|
|
|
Aspiration
|
Turbocharged and intercooled
|
|
|
Rotating speed
|
1500 RPM
|
|
|
Engine cooling system
|
Water-cooled
|
|
|
Fuel system
|
Electronic control injection
|
|
|
Starting method
|
By 24V batteries
|
|
|
Engine filter system
|
Dry type air filter,fuel filter, oil filter, water filter
|
|
|
Displacement(L)
|
16.35
|
|
|
Bore×Stroke(mm)
|
145×165
|
|
|
Compression ratio
|
14.0:1
|
|
|
100% Load fuel consumption (l/h)
|
≤100.9
|
|
|
Lube capacity(L)
|
52
|
|
|
Alternator
|
||
|
Brand
|
SHANHUA
|
|
|
Model
|
HLF400
|
|
|
Excite type
|
Brushless self-excited AVR regulation
|
|
|
Connecting type
|
3 phase 4 pole
|
|
|
Steady frequency change
|
0.50%
|
|
|
No load voltage
|
≥95%-105%
|
|
|
Steady voltage
|
≤±1%
|
|
|
Insulation class
|
Class H
|
|
|
Protection grade
|
IP23
|
|
