Generators set model
|
HL20GF
|
Speed mode
|
Electronic
|
|
Prime power（KW）
|
20
|
Full load fuel consumption rate（g/kwh）
|
202
|
|
Standby power（KW）
|
22
|
Fuel model
|
Normal temperature
|
|
Genset capacity (KVA)
|
25
|
Coolant flow（m3/min）
|
/
|
|
Related speed (RPM)
|
1500
|
Gas volume（m3/min）
|
/
|
|
Related voltage (V)
|
400
|
Smoke exhaust（m3/min）
|
/
|
|
Rated current (A)
|
36
|
Speed mode
|
/
|
|
Related frequency(Hz)
|
50
|
cooling method
|
Closed water cooling
|
|
Rated power factor
|
0.8
|
Oil capacity(L)
|
10.9
|
|
Phase
|
3
|
Coolant capacity (L)
|
7.2
|
|
Reference weight（Kg）
|
650
|
reference weight（Kg）
|
308（Dry weight）
|
|
Reference size (L × W × H)
|
1690*750*1150（mm）
|
Alternator model
|
HLF-20
|
|
Engine model
|
4B3.9-G2
|
Rated voltage (V)
|
400
|
|
Engine related power（KW）
|
24
|
Rated frequency(Hz)
|
50
|
|
Engine standby powe（KW）
|
27
|
Rated speed(RPM)
|
1500
|
|
Engine structural features
|
Four-stroke, turbocharged
|
Power factor
|
0.8
|
|
Cylinders / arrangement
|
6 cylinders/In-line
|
Phase and wiring
|
Three phase Y type
|
|
Bore × stroke（mm）
|
102×120
|
efficiency(%)
|
95.19
|
|
Displacement(L)
|
3.9
|
Excitation method
|
Brushless excitation
|
|
Compression ratio
|
18.0：1
|
Insulation class
|
H
|
|
Start method
|
Electric
|
Protection level
|
IP21
|
